Innovaciones: The Effects of Various Additives on 3D Printed Potatoes

Potato starch is unique among other starches, the author says, in that it has large granules and high swelling power thanks to the presence of a high level of phosphate groups that are covalently linked to the C6 and C3 positions of the glucose monomers. Potatoes can be modified in various ways through cooking and the addition of other ingredients, creating various textures and consistencies.

Dankar points out various reasons for 3D printing food, from making it more accessible to people with difficulty swallowing to making it more appealing to children.

“The main purpose of this thesis was to determine and optimize the ideal conditions for best extrusion 3D printing and best printed end product, by characterizing the physical, chemical, microstructural and rheological properties of the material mixture to be printed, in this case potato puree combined with different food additives, in complementary with optimizing the printing process parameters its self,” Dankar explains.

To fulfill the main objective, the following particular objectives were determined:

Assessing the changes induced by food additives on the microstructure and rheological properties of potato puree

Understanding the changes tempted by food additives on potato puree in terms of the internal molecular level

Characterizing the mechanical energy and specific mechanical energy of each blend, and relating all the previous characteristics while performing 3D printing trials while optimizing some process parameters of the 3D printer in accordance of the printed substrate as well

Analyzing the effect of cooking treatment (microwave and boiling) and water presence on the molecular structure of starch in an attempt to develop such a material (this time potato tubers) for 3D printing

Interpreting the effect of different additives inserted as well as cooking treatment (microwave and boiling) on the mechanical, rheological and microstructure aspects of potato tubers, while identifying the substrate blend with the ideal characteristics for best 3D printing

The study found that the additives agar and alginate stabilized the potato puree, while glycerol and lecithin demonstrated a destabilizing effect. Cooking processes affected the rheological properties of the potatoes; microwaved samples expressed higher values than boiled potato samples in terms of viscosity, yield stress and thixotropy. The addition of olive oil acted as an emulsifier and decreased the viscosity and yield stress in both microwaved and boiled samples.

The best conditions for 3D printing potatoes were achieved with a 4mm nozzle size and a 0.5 cm critical nozzle height using a printing material made from potato puree and alginate or agar. All of the samples achieved relatively good printability, but the best printability was achieved with a mixture of potatoes and butter.

“Commercial potato puree samples prepared from mashed potatoes and combined with different food additives at different concentrations possessed all non-Newtonian, shear-thinning behavior, which is favorable for the flow behavior through a syringe during extrusion 3D printing,” Dankar concludes.

Overall, Dankar determined that potatoes are a strong candidate for 3D printing overall, with or without any number of additives.
